AW J5P CA3224 6×4 Tipper Truck for Sale — 290HP Weichai, 21.5T Payload

Name: AW J5P CA3224 6×4 Tipper Truck for Sale — 290HP Weichai, 21.5T Payload
SKU: SKU-475

The FAW J5P CA3224 is a heavy-duty 6×4 tipper truck engineered for Africa, the Middle East, and developing-market construction and mining applications. Powered by the Weichai WP10.290E32 9.726-litre engine producing 290 HP and mated to a FAST 9JS119 9-speed manual gearbox, it delivers dependable torque under full load. The truck carries a manufacturer's GVW of 35,000 kg and a maximum payload of 21,500 kg, supported by 300-series hub-reduction rear axles, Triangle 12.00R20 or 315/80R22.5 radial tyres, and WABCO-valved air brakes.

Truck & Special vehicles FAW

Contact Us for Pricing

Interested in this product? Contact us now for detailed pricing and product information.

Product Details

Dump Truck
FAW — J5P Series

FAW J5P CA3224 290HP 6×4 Tipper Truck

The FAW J5P CA3224 is a purpose-built 6×4 heavy tipper designed for demanding construction, mining, and infrastructure applications in developing markets. Powered by a Weichai WP10.290E32 Euro II diesel producing 290 HP, mated to a FAST 9-speed gearbox and heavy-duty hub-reduction rear axles, it delivers a maximum payload of 21,500 kg and 15.5 CBM tipper capacity. The flat-roof single-sleeper cab with sunroof and full air conditioning ensures all-day driver comfort, while WABCO brake valves and CAMEL maintenance-free batteries underline the truck’s reputation for road-proven reliability across Africa and the Middle East.

Basic Information

Brand	FAW (First Automobile Works) — China
Model	CA3224 — New J5P Series
Drive Configuration	6×4 (Left-Hand Drive)
Manufacturer’s GVW	35,000 kg
Maximum Payload	21,500 kg
Curb Weight	13,500 kg
Overall Dimensions (L×W×H)	8,223 × 2,500 × 3,300 mm
Wheelbase	3,700 + 1,350 mm
Front Axle Max. Load	7,500 kg
Rear Tandem Axle Max. Load	16,000 kg × 2
Emission Standard	Euro II
Condition	Brand New · Factory Direct

Engine & Powertrain

Engine Model	Weichai WP10.290E32
Displacement	9.726 L (Inline 6-cylinder)
Horsepower	290 HP (213 kW)
Emission Level	Euro II
Transmission	FAST 9JS119 — 9 Forward + 1 Reverse
Rear Axle Type	300 Casting Axles / Hub Reduction
Frame (Main Rail)	320 × 90 × (8+8) mm high-strength steel
Fuel Tank Capacity	400 L

Tipper Body

Body Dimensions (L×W×H)	5,200 × 2,300 × 1,300 mm
Approximate Volume	~15.5 CBM
Floor Thickness	8 mm high-strength steel
Sideboard Thickness	6 mm
Tipping Method	Hydraulic rear-tipping
Typical Applications	Construction earthwork, quarrying, mining overburden, sand & gravel, road building

Tyres & Running Gear

Tyre Model	Triangle (Tube) 12.00R20-18 or (Tubeless) 315/80R22.5-20
Tyre Type	Radial — 10 running + 1 spare
Brake Valves	WABCO (all valves)
Battery	CAMEL maintenance-free

Cab & Standard Features

Cab Style	New J5P — Flat roof / Semi-floating / Single sleeper
Sunroof	Standard
Air Conditioning	Standard (factory AC)
Guard Plate	Water tank guard plate — standard
Front Panel & Bumper	All-steel front panel and bumper
Fuel Consumption	~35 L/100 km
After-Sales Service	24/7 support · Sufficient parts stock · Worldwide DDP delivery

Why Choose the FAW J5P CA3224?

290 HP Weichai Power

The WP10.290E32 is a field-proven inline-six delivering reliable torque for steep grades, fully loaded at 35-tonne GVW, even in extreme heat.

Hub-Reduction Rear Axle

300-series casting axles with hub reduction multiply traction and ground clearance — purpose-built for rough quarry and construction-site terrain.

WABCO Brakes + CAMEL Battery

International-standard safety components — WABCO brake valves and CAMEL maintenance-free batteries minimise downtime and repair costs in remote markets.
