Used SANY SCC3200A-1 Crawler Crane — 320 Ton Lattice Boom Crane

Name: Used SANY SCC3200A-1 Crawler Crane — 320 Ton Lattice Boom Crane
Brand: SANY
SKU: used-sany-scc3200a-1-crawler-crane
Availability: InStock

Pre-owned SANY SCC3200A-1 lattice boom crawler crane with 320 t maximum lifting capacity, 1,820 t·m lifting moment, and 20–86 m boom. Cummins QSL8.9 242 kW engine, SYIC-II control system, full LMI safety package. Inspected, load-tested and export-ready with DDP worldwide delivery.

Lifting crane, Used Heavy Machinery SANY, SANY crawler crane, Used crawler crane, Used SANY crane

Contact Us for Pricing

Interested in this product? Contact us now for detailed pricing and product information.

Product Details

Used · Pre-OwnedSANY SCC3200A-1 · 320 Ton · Lattice Boom Crawler Crane

Used SANY SCC3200A-1 Crawler Crane — 320 Ton Lifting Capacity

The SANY SCC3200A-1 is a heavy-duty lattice boom crawler crane in the 320-ton class, built for wind farm installation, petrochemical lifting, bridge and power-plant projects. This pre-owned unit is function-tested, load-tested and export-ready. With a 20–86 m boom, 1,820 t·m lifting moment, and hook blocks from 16 t to 300 t, it covers the full range of heavy lifting jobs at a fraction of new-machine cost.

Basic Information

Model	SCC3200A-1
Crane Type	Lattice boom crawler crane
Max. Rated Lifting Capacity	320 t
Max. Lifting Moment	1,820 t·m
Boom Length	20 – 86 m
Boom Angle	30° – 85°
Max. Fixed Jib (boom + jib)	62 + 42 m
Max. Luffing Jib (boom + jib)	62 + 60 m
Slewing Speed	0 – 1.0 rpm
Travel Speed	0–1.2 / 0–0.53 km/h (high / low)
Gradeability	30%
Average Ground Pressure	0.14 MPa
Working Hours / Year	[ Fill in: e.g. 3,200 h · 2019 ]

Engine & Powertrain

Engine Model	Cummins (DCEC) QSL8.9-C325 — 4-stroke, water-cooled, inline 6, turbo + intercooler
Emission Standard	Non-road Tier III
Displacement	8.9 L
Rated Power	242 kW / 2,100 rpm
Max. Torque	1,385 N·m / 1,500 rpm
Fuel Tank Capacity	1,050 L
Hydraulic Tank Capacity	500 L
Max. Hydraulic Pressure	33 MPa
Control System	SYIC-II integrated control, CAN BUS, LMI, remote monitoring

Hoist & Working Speed

Main / Aux. Load Hoist (single rope)	0 – 120 m/min
Boom Hoist Winch	0 – 130 m/min
Jib Hoist Winch	0 – 100 m/min
Main Load Hoist Rope Length	650 m (Ø26 mm)
Aux. Load Hoist Rope Length	390 m (Ø26 mm)
Boom Hoist Rope Length	345 m (Ø28 mm)

Counterweight & Hook Blocks

Carbody Counterweight	2 × 20 t
Rear Counterweight Blocks	14 × 8 t (self-assembly tray)
Rear Counterweight Tray	1 × 12 t
Hook Block Options	300 / 260 / 200 / 160 / 100 / 50 t + 16 t ball hook
Track Pad Width	1,200 mm (79 pads × 2)

Transport & Dimensions

Basic Machine (L × W × H)	13.32 × 3.00 × 3.20 m
Basic Machine Weight	45.0 t (max single transport part)
Crawler (each, L × W × H)	9.75 × 1.57 × 1.42 m · 22.93 t
Shipping Breakdown	Crawlers, counterweight blocks, boom/jib inserts, hooks — standard container/flat-rack shipping

Condition & Inspection (This Unit)

Working Hours	[ Fill in meter reading, e.g. 3,200 h ]
Manufacturing Year	[ Fill in, e.g. 2019 ]
Condition Grade	[ A / B / C ] — photos & video available on request
Function & Load Test	Full function test and rated load test before shipment
Maintenance Records	[ Available / on request ]
Optional Refurbishment	Repaint, new wear parts, new ropes, full service

Safety & Control Systems

Load Moment Limiter (LMI): computerized safety control with black-box lifting record, auto cut-off toward dangerous direction.
Emergency Stop: cuts all power and halts every action in one press.
Over-hoist & Boom Limit Devices: protect hook and boom at extreme positions.
Swing Lock & Function Lock Lever: prevent mis-operation during transport and idle.
SYIC-II Control + Remote Monitoring: GPS, GPRS, fault self-diagnosis, real-time data to mobile app.
Tri-color Load Indicator & Anemometer: real-time load status and wind-speed warning.

Why Choose This Used SCC3200A-1?

320-ton class at used price: same lifting capacity as a new unit, at a fraction of the capex.
Immediate availability: no long production lead time — ships once inspection is done.
Versatile boom & jib range: 20–86 m boom with fixed and luffing jib for wind, petro, bridge and foundation work.
Proven SANY reliability: Cummins-powered, SYIC-II control, full LMI safety package.
Export-ready: inspected, load-tested, DDP worldwide with customs clearance.
Spare parts support: genuine SANY parts and ArcherMach after-sales backup.
