HT90 Large Excavator — 9-Ton Class Heavy-Duty Crawler

Name: HT90 Large Excavator — 9-Ton Class Heavy-Duty Crawler
Brand: ArcherMach
SKU: ht90-large-excavator
Availability: InStock

The HT90 stands as the heaviest and most powerful model in China's complete excavator product lineup. With an operating weight of 9000 kg (9 tons), this machine represents true heavy-duty capability for demanding construction projects requiring maximum productivity and raw digging power.

Excavator OEM Equipment

Contact Us for Pricing

Interested in this product? Contact us now for detailed pricing and product information.

Product Details

HOT SALE
HEAVIEST MODEL
9-TON CLASS

HT90 Large Excavator — 9-Ton Class Heavy-Duty Crawler

Heaviest in HT Series · 9000 kg · Kangming QSF2.8 53kW · 7050mm Max Height · 58kN Breakout Force · 27.5MPa Hydraulics

9000 kg
Operating Weight

53 kW
Engine Power

7050 mm
Max Dig Height

58 kN
Breakout Force

HT90 Large Excavator Overview

The HT90 stands as the heaviest and most powerful model in China’s complete excavator product lineup. With an operating weight of 9000 kg (9 tons), this machine represents true heavy-duty capability for demanding construction projects requiring maximum productivity and raw digging power.

Powered by a robust Kangming QSF2.8 diesel engine certified to Tier 3 / Stage III emission standards, delivering 53 kW (approximately 72 HP) at 2200 RPM through its 4-cylinder direct-injection architecture. This proven powerplant provides ample torque reserve for heavy earthmoving tasks while maintaining competitive fuel economy.

The hydraulic system operates at a professional-grade 27.5 MPa system pressure, generating an impressive 58 kN bucket breakout force and 40 kN arm crowd force. With a 0.4 m3 bucket capacity and a 7050 mm maximum digging height (over 7 meters), the HT90 excels at high-side truck loading, deep foundation excavation, large-scale land grading, and heavy-duty construction applications where smaller machines simply cannot deliver the required output.

Key Specifications

Parameter	Specification	Parameter	Specification
Operating Weight	9000 kg (9-Ton Class)	Engine Model	Kangming QSF2.8
Bucket Capacity	0.4 m³	Rated Power	53 kW (72 HP) @ 2200 RPM
Emission Standard	Tier 3 / Stage III	Cylinders	4-Cylinder Direct Injection
Max Digging Height	7050 mm	Max Digging Depth	5188 mm
Max Digging Reach	4015 mm	Max Swing Radius	6540 mm
Breakout Force	58 kN	Arm Crowd Force	40 kN
Hydraulic Pressure	27.5 MPa	Travel Speed	2.3 / 4 km/h
Fuel Tank	110 L	Hydraulic Tank	100 L

Dimensions & Undercarriage

Parameter	Specification	Parameter	Specification
Overall Length (L)	6410 mm	Overall Width (W)	2278 mm
Overall Height (H)	2630 mm	Cabin Height	2630 mm
Tail Swing Radius	1813 mm	Min Ground Clearance	375 mm
Track Gauge (Wheelbase)	2209 mm	Track Width	1750 mm
Min Swing Radius	2140 mm	Track Shoe Width	450 mm
Track Shoes Per Side	39 pcs	Bottom Rollers Per Side	5 pcs

Working Range & Performance

Parameter	Value	Parameter	Value
Max Digging Height	7050 mm	Max Digging Depth	5188 mm
Max Digging Reach	4015 mm	Max Swing Radius	6540 mm
Vertical Wall Dig Depth	3550 mm	Min Swing Radius	2140 mm
Bucket Breakout Force	58 kN	Arm Crowd Force	40 kN
Travel Speed (Low)	2.3 km/h	Travel Speed (High)	4 km/h

Engine System

Parameter	Specification
Engine Brand / Model	Kangming QSF2.8 — Proven diesel engine widely used in Chinese construction equipment exports
Emission Certification	Tier 3 / Stage III — Compliant with major international emission regulations for export to Africa, Southeast Asia, Middle East, South America, and other markets
Cylinder Configuration	4-Cylinder, Direct-Injection Diesel — Balanced power delivery with excellent fuel efficiency for all-day operation
Rated Power Output	53 kW (approx. 72 HP) @ 2200 RPM — Sufficient power reserve for heavy earthmoving, steep incline climbing, and continuous duty cycles
Fuel Tank Capacity	110 Liters — Provides extended operational runtime between refueling stops for productive work shifts

Hydraulic System

Parameter	Specification
System Working Pressure	27.5 MPa — High-pressure system delivers maximum digging force, lifting capacity, and attachment performance for professional-grade earthmoving
Hydraulic Tank Capacity	100 Liters — Adequate oil volume ensures stable temperature under sustained heavy-duty operation in hot climate conditions
Bucket Breakout Force	58 kN — Powerful breakout force for breaking compacted soil, hard-packed clay, rocky terrain, and loading dense materials with high efficiency
Arm Crowd (Stick) Force	40 kN — Substantial crowd force enabling deep digging penetration, aggressive trenching, and efficient material handling in tough ground conditions

Undercarriage & Track System

Parameter	Specification
Track Type	Steel Crawler Tracks — Heavy-duty steel track system designed for rugged construction site conditions, rocky terrain, and long service life
Track Gauge (Wheelbase)	2209 mm — Wide track gauge provides excellent stability during side-slope operation and swing maneuvers
Track Width	1750 mm — Wide track footprint reduces ground pressure and improves stability on soft or uneven terrain
Track Shoe Width	450 mm — Wide track shoes maximize surface contact for superior flotation on soft ground conditions
Track Shoes Per Side	39 pieces — Long track length provides even weight distribution and smooth travel over uneven surfaces
Bottom Rollers Per Side	5 pcs — Multiple bottom rollers distribute machine weight evenly across the track frame
Top Rollers Per Side	1 pc
Travel Speed (Low Gear)	2.3 km/h — Low-speed precision mode for accurate positioning and fine control during digging operations
Travel Speed (High Gear)	4 km/h — Higher travel speed for efficient repositioning between work areas within the job site

Key Features

✅ True 9-Ton Capacity	9000 kg operating weight with 0.4 m3 bucket capacity — handles serious earthmoving, heavy-duty loading, and large-scale excavation tasks that smaller machines cannot efficiently perform
✅ 7050 mm Maximum Digging Height	Over 7 meters of vertical reach for loading high-side dump trucks, skip loaders, and elevated earthmoving applications with comfortable clearance margin
✅ 58 kN Powerful Breakout Force	Industry-leading breakout force powered by 27.5 MPa hydraulic system pressure — excels at breaking hard soil, compacted clay, rocky ground, and loading dense materials
✅ 5188 mm Deep Digging Capability	Deep excavation capacity for foundation footings, basement digging, drainage systems, pipeline trenching, pool excavation, and utility installation
✅ 6540 mm Wide Swing Radius	Maximum 6.54-meter swing working radius covers large areas without frequent machine repositioning, maximizing operational efficiency per hour
✅ Kangming QSF2.8 Tier 3 Engine	Proven 4-cylinder diesel engine with Tier 3 / Stage III certification for broad market acceptance. 53 kW output balances power and fuel economy for cost-effective operation
✅ Wide Heavy-Duty Undercarriage	450 mm wide track shoes, 39 shoes per side, 1750 mm track width, 2209 mm wheelbase — engineered for stability, durability, and excellent flotation on challenging terrain

Applications

Heavy Earthmoving

Large-scale land clearing, bulk excavation, embankment building, cut-and-fill operations, and mass earthmoving for commercial and industrial developments

Road & Highway Construction

Highway sub-grade excavation, bridge foundation digging, roadbed preparation, culvert installation, roadside drainage ditching, and slope stabilization

Foundation & Basement Work

Building foundation excavation, basement digging, footing trenching, pile cap excavation, and deep utility trenching for commercial structures

Quarry & Mining Support

Material handling, stockpile management, crusher feeding, bench cleaning, overburden removal, and secondary breaking support in aggregate operations

Infrastructure Projects

Pipeline trenching, water/sewer main installation, cable conduit laying, drainage system construction, retention pond excavation, and utility corridor preparation

Demolition & Site Clearing

Structure dismantling, concrete breaking, debris sorting and removal, foundation tear-out, and post-demolition site cleanup and grading

Why Choose Archer Machinery as Your Export Partner?

Since 2017	JINAN ARCHER TRADE CO., LTD has been exporting Chinese construction machinery and trucks since 2017 with deep manufacturer relationships ensuring priority allocation and best pricing
9 Premium Brands	Authorized distributor for XCMG, SANY, Zoomlion, Shantui, SDLG, YTO (construction) + SINOTRUK, SHACMAN, FAW (trucks). Full product range from one partner
Global Shipping	FOB/CIF/DDP to 60+ countries. Experienced with customs clearance, export documentation, and multi-unit container consolidation
OEM Private Label	Full white-label capability: your logo, your colors, your brand. We handle production coordination so you can focus on sales and distribution
Spare Parts Supply Chain	Kangming engine spare parts, hydraulic components, wear parts, undercarriage components, and attachments shipped worldwide with fast lead times
Multi-Language Support	English, Spanish, Russian, Arabic, French communication. Time zone-friendly response from our international trade team in Jinan, China

Get HT90 Large Excavator Quote Today

Shandong Hightop HT90 — 9000 kg flagship, Kangming QSF2.8 Tier 3 engine 53kW (72HP), 7050 mm digging height, 5188 mm depth, 58 kN breakout force, 27.5 MPa hydraulics, 0.4 m3 bucket. FOB China pricing for global B2B buyers.
