It has adopted advanced design and manufacturing methods and the latest standards in accordance with the product design concept of “high efficiency, excellent energy saving and outstanding environmental protection.
Model Characteristics:
1. Ecological and economical * The ISUZU engine with point-type fuel injection technology provides strong power. * The negative flow control system with double-pump confluency realizes efficient operating. * Smart electronic control system can achieve dynamic balance of power and hydraulic system.
2. Multiple applications * Different boom, arm and bucket combinations to maximize utilization of different conditions. * Multi-functional machine system meets various job requirements such’ as digging, crushing, and thumb clamp. * ESS microcomputer power control system maintains the best efficiency and economy.
3. Comfortable operational experience * High-performance silicone oil shock absorber improves comfort. * Air Conditioner and Heater ensure the appropriate temperature. * Integrated control panel and large display screen provide multiple information.
We also provide XCMG SPARE PARTS FOR EXCAVATOR
|
Description
|
Unit
|
XE370CA
|
|
|
Operating weight
|
kg
|
36600
|
|
|
Bucket capacity
|
m³
|
1.4～1.8
|
|
|
Engine
|
Model
|
Engine
|
ISUZU AA-6HK1XQP
|
|
Direct injection
|
—
|
√
|
|
|
Four strokes
|
—
|
√
|
|
|
Water cooling
|
—
|
√
|
|
|
Turbo-charging
|
—
|
√
|
|
|
Air to air intercooler
|
—
|
√
|
|
|
No. of cylinders
|
—
|
6
|
|
|
Output power
|
kW/ r/min
|
190.5/2000
|
|
|
torque/speed
|
N.m
|
872.8/1700
|
|
|
Displacement
|
L
|
7.79
|
|
|
Travel speed（H/L)
|
km/h
|
5.4/3.2
|
|
|
Main performance
|
Gradeability
|
%
|
70
|
|
Rotary speed
|
r/min
|
9.6
|
|
|
Ground pressure
|
kPa
|
66.6
|
|
|
Bucket digging force
|
kN
|
263
|
|
|
Arm digging force
|
kN
|
225
|
|
|
Working scope (2.71m arm)
|
Max. dumping height
|
mm
|
6947
|
|
Max. digging depth
|
mm
|
6927
|
|
|
Max. digging depth at the range of level 8 feet
|
mm
|
6709
|
|
|
Max. vertical wall digging depth
|
mm
|
5312
|
|
|
Max. digging reach
|
mm
|
10470
|
|
|
Min. swing radius
|
mm
|
4424
|
|
|
Working scope (2.5m arm)
|
Max. digging height
|
mm
|
9891
|
|
Max. dumping height
|
mm
|
6820
|
|
|
Max. digging depth
|
mm
|
6786
|
|
|
Max. digging depth at the range of level 8 feet
|
mm
|
6666
|
|
|
Max. vertical wall digging depth
|
mm
|
4914
|
|
|
Max. digging reach
|
mm
|
10414
|
|
|
Min. swing radius
|
mm
|
4416
|
|
|
Worker Standard
|
Length of boom
|
mm
|
6400
|
|
Length of arm
|
mm
|
2670
|
|
|
Bucket capacity
|
m³
|
1.6
|
|
|
Worker Optional
|
Length of arm
|
mm
|
2900/3200/4000
|
|
Bucket capacity
|
m³
|
1.4/1.5/1.8
|
|
