WT1405 Big Skid Steer Loader

♦ Vertical lifting type and 2540mm discharging height make perfect loader; ♦ More than 20 series attachments for option: pallet fork, hydraulic hammer, backhoe,sweeper, angle broom, 4 in 1 bucket, auger, trencher, tooth bucket and so on; ♦ Attachment can be used with bobcat type skid steer loader; ♦ World famous parts from German (Rexroth pump, double speed motor right-left operating joystick) ♦ World famous parts from America (America electromagnetic valve, hydraulic balance valve, bearing and three stage air filter) ♦ EUROIII UK Perkins engine ; ♦ Multifunctional, maneuverable and reliable;

Category: Skid Steer Loader

Description
Reviews (0)

WT1405 Big Skid Steer Loader adopt Euro Ⅲ Uk Perkins Engine 1104d-e44ta 87kw;
Rexroth (Pump;Double Speed Motor With Parking Brake;Control Valve With Safty Lock;Hydraulic Joystick)
America (Electromagnetic Valve;Hydraulic Balance Valve；3 Stage Air Filter)
Closed Cab With Heater,fan,warning Light;
Reverse Buzzer;
12-16.5 Tubeless Tire 12-16.5;
Mirror Outside Cab;

Hot Tags: WT1405 big skid steer loader, China, manufacturers, factory, buy, cheap, discount, quotation, pricelist, low price, in stock

Technical Data		Model	1405
A	Overall Operating Height	mm	4086
B	Height to Bucket Hinge Pin	mm	3150
C	Height to Top of Cab	mm	2028
D	Height to Bottom of Level Bucket	mm	2960
E	Overall Length without Bucket	mm	2833
F	Overall Length with Bucket	mm	3623
G	Dumping Angle at Maximum Height		40°
H	Dumping Height	mm	2465
I	Dumping Reach	mm	610
J	Rollback of Bucket on Ground		30°
K	Rollback of Bucket at Full Height		94.6°
L	Wheelbase	mm	1150
M	Ground Clearance	mm	210
N	Angle of Departure		26°
O	Turning Radius Front without Bucket	mm	1350
P	Front Turning Radius	mm	2210
Q	Rear Turning Radius	mm	1786
R	Rear Axle to Bumper	mm	1070
S	Tread Width, Centerline to Centerline	mm	1506
T	Width	mm	1850
U	Bucket Width	mm	1980
